Digital Viscometers
Leading Manufacturers and Wholesaler of Digital Viscometer SI-V195, Digital Viscometer SI-V201 and Digital Viscometer SI-V205 from Zirakpur.
| Business Type | Manufacturer, Supplier |
| Click Here To View Catalog |  View |
| Weight | 6.8 Kg |
| Display | LCD |
| Measuring Range | 20-2,000,000 M.pas |
| Number Of Standard Spindles | #1, #2, #3, #4 |
| Measurement Accuracy | ±1.0% Of Range |
| Repeatability | ±0.5% |
| Temperature Monitoring | RTD Sensor Probe |
| Output Interface | RS 232 |
| Environment Temperature | 5-35 C |
| Relative Humidity | ≤80% |
| Dimensions | 370 X 325 X 280 Mm |
Digital viscometers operate on the principle of how a fluid’s internal friction affects its flow behavior. They typically measure the time it takes for a given amount of fluid to flow through a specific geometry (usually a capillary tube or rotating spindle) under controlled conditions. The measurement is then used to calculate the fluid’s viscosity
Applications :
- Dairy Products
- Juices, etc.
- Pharmaceuticals
- Polymer Solutions Oils Paints
- Inks latex Adhesives (Solvent Base)
- Coatings Solvents
Advantages of Digital Viscometers :
- High precision and accuracy in viscosity measurement.
- Quick and repeatable measurements.
- Can be used for a wide range of fluid types, from low to high viscosities.
- Some models can measure at different shear rates, providing valuable information about the fluid’s behaviour under different conditions.
Features :
- Stepping Motor means Accurate, reliable operation
- Direct readout of all measurement parameters
- Auto Range Showing
- Time Function for measurement
- Sound alarm at under 20% Torque
- Linear calibration
- Wide range power supply:100V-240V
| Business Type | Manufacturer, Supplier |
| Click Here To View Catalog | View |
| Weight | 9 Kg |
| Power Supply | AC 220V/50 Hz |
| Display | LCD Touch Screen |
| Country of Origin | India |
| Measuring Range m.P.A.S. | 10 - 2,000,000 mPAS |
| RPM | 0.3, 0.6, 1.5, 3, 6, 12, 30, 60 |
| No. of Standard Spindles | #1, #2, #3, #4 is standard configuration (#0 is for option) |
| Measurement Accuracy | ±1.0 % of Range |
| Repeatability | ±0.5 % |
| Output | RS 232 Interface |
| Dimensions L X H X B (mm) | 400 X 350 X 360 |
Digital Viscometer is a touch screen compact and easy to operate instruments with auto range showing time function for measurements. This is a unique system that combines convenience with accuracy and precision in analysis.
Features :
- Touch screen compact and easy to operate
- Auto range showing time function for measurements
- Sound alarm at under 20% torque, linear calibration
Applications :
- Pharmaceuticals
- Coating Solvents
- Polymer Solution
- Oil Paints
- Inks Latex Adhesives
- Juices and Dairy Products
| Business Type | Manufacturer, Supplier |
| Click Here To View Catalog | View |
| Weight | 9 Kg |
| Power Supply | AC 220V/50 Hz |
| Display | LCD Touch Screen |
| Country of Origin | India |
| Measuring Range m.P.A.S. | 10 - 2,000,000 mPAS |
| RPM | 0.3, 0.6, 1.5, 3, 6, 12, 30, 60 |
| No. of Standard Spindles | #1, #2, #3, #4 is standard configuration (#0 is for option) |
| Measurement Accuracy | ±1.0 % of range |
| Repeatability | ±0.5 % |
| Output | RS 232 Interface |
| Dimensions L X H X B (mm) | 400 X 350 X 360 |
Digital Viscometer is a touch screen compact and easy to operate instruments with auto range showing time function for measurements. This is a unique system that combines convenience with accuracy and precision in analysis
Features :
- Touch screen compact and easy to operate
- Auto range showing time function for measurements
- Sound alarm at under 20% torque, linear calibration
Applications :
- Oil Paints
- Inks Latex Adhesives
- Juices and Dairy Products
- Pharmaceuticals
- Coating Solvents
- Polymer Solution
