Water and Soil Analysis Kit


SI-157 Water and Soil Analysis Kit
Send Enquiry


Details

Display pH
Range 0 to 14 ph
Resolution 0.01 ph
Accuracy 0.01 ± 1 digit
Temp.comp. 0-100ºc (manual)
Temperature
Range 0-100ºc
Resolution 0.1ºc
Accuracy ±0.10c± 1digit
Sensor Semi conductor type
Tds
Range 0-20 ppt 0-200 ppm
Range selection Manual
Resolution 0 -01 ppt
Accuracy ±0.5% fs ±1digit
Cell constan t Pre-adjusted 0.4
To 1.5 on display
Do
Range 0-20 ppm
Resolution 0.1 ppm
Accuracy 0.5 ppm ± 1 digit
Temp.comp. Manual(50cto 550c)
Do sensor Gold/silver amperometric probe
Conductivity (EC)
Range 0-20ms
0-200 μs
Resolution 0.01ms (10μs) 0.01μs
Range selection Manual
Accuracy ± 0.5 % fs ± 1 digit
Cell constant pre-adjusted Adjustable ( 0.4 to 1.5)
Temp.coefficent 2.00% 2%
Temp.comp. Adjustable from table
Reference temp. 25c
Salinity
Range 0-50 ppt 0-50 ppt
Resolution 0.1 ppt 0.1 ppt
Accuracy ± 0.5%fs ± 1digit
Power supply 12v rechargeable
Battery or 230v±10%ac,50hz
Turbidity
Range 0-1000 ntu
Resolution 1 ntu
Accuracy ±3% fs ± 1 digit
Sample system 30 mm clear glass tube

The diverse range of Digital Water & Soil Analysis Kit catered by us is of top-notch quality and is manufactured using quality raw material and advanced technology. Our experts and engineers are capable enough to maintain pace with the latest trend of the marketplace. Further, we can custom design the range as per the specifications of the clients in the stipulated time frame.




Salient Features

  • Mains cum battery operated
  • Available in abs plastic briefcase
  • Measures pH, conductivity, TDS, DO, Salinity, Temperature and Turbidity Meter.


Accessories

  • Combined pH Electrode
  • Cond./TDS/Salinity Cell
  • Temp. Probe
  • DO Probe
  • DO Membrane
  • 100ml Bottles  One Pair
  • Solution/Tablets  7pH & 4pH 4
  • 30mm Clear Glass Tubes
  • Main Lead
  • Operation Manual

Yes! I am interested


SI-159 Water and Soil Analysis Kit
Send Enquiry


Details

SI-159 Ph Conductivity Tds Do Mv/orp Salinity Temperature Turbidity *
Range 0 to 14 ph 0.00 µs/cm to
1000 ms/cm
In 6 auto ranges
0.00 ppm to 200 ppt in 5 auto ranges 0 to 20 ppm -1999 to +1999 mv 0- 50 ppt -20 °c to 200°c 0 to 1000 ntu
In 2 ranges
Resolution 0.01 ph 0.01, 0.1,1 µs/cm or ms/cm as per range 0.01, 0.1, 1 ppm or ppt as per range 0.1 ppm 1 mv 0.2 ppt 0.1 °c 0.1 ntu in lowest range
Accuracy +0.01 ph +0.5% +0.5% +0.2 ppm  +1 digit +0.2 ppm  +1 digit +0.5% +0.2%  +  1digit +3%fs  +1 digit
Calibration Auto & manual ---- ---- Auto & manual Auto & manual ---- Manual Manual
Temperature
compensation
0-100 °c  (auto/manual) --   --   0-100 °c  (auto/manual)   0-100 °c  (auto/manual) ---- ----
Auto buffer
recognition
4.00, 7.00 & 9.20 ---- ---- ---- ---- ---- ---- ----
Range selection ---- Automatic Automatic ---- ---- ---- ---- Automatic
Cell constant
adjustment
---- 0.05 to 2.0 (auto/manual) 0.05 to 2.0 (auto/manual) ---- ---- ---- ---- ----
Temperature
coefficient
---- 0-4% adjustable ---- ---- ---- ---- ---- ----
Salinity factor ---- ---- ---- ---- ---- ---- ---- ----
Tds factor ---- ---- Adjustable(0.5 by default) ---- ---- ----- ---- ----
Salinity correction ---- ---- ---- 0 to 20 mg/l ---- ----- ---- ----





Salient Features

  • 16x2 alpha numeric backlit LCD display
  • Temperature and parameter display simultaneously
  • Real time display in 24 hour format
  • Simple menu driven controls using soft keys
  • Storage upto 1000 samples
  • 230 V + 10% 50 Hz with inbuilt 12V rechargeable battery
  • Serial RS-232 and parallel centronics computer interface
  • Print selection - datewise or all data


Standard Accessories : pH Electrode, Buffer solutions (4.00, 7.00), Conductivity/TDS/Salinity Cell, DO Probe, DO Membrane Temperature Probe, ORP Electrode (at extra cost), Operation Manual, Data cable

Turbidity is available in Model SI-159 with following additional specifications:

  • Sample System: 30 mm clear glass test tube
  • Light Source: 6V tungsten lamp
  • Detector: Photodiode/photocell
